Electronic Control	72V/400A Programmable AC Controller
Battery	6V/200AH, 12 units/72V Maintenance-free Battery
Motor	72V/7.5KW AC Asynchronous Motor
Charger	72V/30A Intelligent Pulse Portable Charger
Charging Time	8-10 hours (Discharge Rate: 80%)
Input Voltage	AC-220V
Technical Parameters
Technical Parameters				Dimensions (L×W×H)	4260×1730×2120mm (±20mm)	Braking Distance	5m (at 20km/h)
Box Size	2485×1400×1175mm (±30mm)	Maximum Loading Capacity	3m³
Curb Weight	1400kg (±30kg)	Maximum Speed	30km/h
Maximum Load	≤1000kg	Driving Range (Unloaded)	80km
Front/Rear Wheel Track	1200/1200mm±20	Maximum Gradient	15%
Wheelbase	2330mm (±20mm)	Minimum Turning Radius	5.5m
Oil Pump Noise	≥70db	Minimum Ground Clearance	150mm
Side Roll Lifting Time	≥14s	Side Roll Lowering Time	≥16s
Body System
Body System
Seat	Two single driver seats (leather fabric + high-resilience PU, light gray, formed armrests)
Vehicle Body	Steel frame + FRP (Fiberglass Reinforced Plastic) shell
Pushing Device	Optional: Built-in pushing device in the box (pushes garbage backward)
Instrument	High-precision meter (battery gauge/ammeter/voltmeter/hour meter, etc.)
Rearview Mirror	Manual external rearview mirror
Lights & Signals	Combined front lights, turn signals, combined rear tail lights, brake lights, sanitation work lights, electric horn, and reversing buzzer
Audio System	On-board MP3 speaker, reversing camera + GPS positioning
Switches	Start switch, light & wiper combination switch, emergency light switch, emergency stop switch, lever-type forward/reverse switch
Front Windshield	Standard automotive double-layer laminated glass (3+1+3)
Frame	High-performance steel frame with surface rust-proof treatment
Steering Wheel	Polyurethane foam steering wheel
Steering Mode	Handlebar steering
Chassis System
Chassis System
Power Transmission	Coupled stepless speed regulation system
Steering System	Rack and pinion steering gear
Power Steering	EPS (Electric Power Steering) system
Front Axle & Suspension	Full-floating integral front axle + high-strength leaf spring + tubular hydraulic shock absorber
Rear Axle & Suspension	Full-floating integral rear axle, high-strength leaf spring, tubular hydraulic shock absorber
Braking System	Front and rear drum 220 hydraulic brakes, dual-circuit hydraulic braking with vacuum brake booster, parking brake
Tires	13×4.5 steel wheel hubs, reinforced tubeless radial tires 165R13LT
Hydraulic Lifting Mechanism	Button-type automatic linkage with lifting mechanism
Power Unit	72V long-time 1200W, multiple solenoid valve coils
