| Diesel Engine | Model | Cummins 6BTA5.9-C180 (turbocharged |
| and charge water cooled) | ||
| Displacement | 5.9L (1.56 US Gallons) | |
| Power | 132Kw (180HP) | |
| Rated RPM(Factory setting) | 2200rpm | |
| Drilling Capacity | BQ | 1050m(3280feet) |
| NQ | 700m(2296 feet) | |
| HQ | 500m(1640 feet) | |
| PQ | 300m(984 feet) | |
| Mud Pump | Type | Reciprocating pump Triplex Plunger |
| Model | BW160/10 | |
| Stroke | 70mm(2.76 inch) | |
| Discharge pressure | 2.5, 4.0, 6.5, 10.0 Mpa | |
| (363, 580, 943, 1450 psi) | ||
| Foot Clamp | Clamping Scope | 55.5-110 mm(2.19-4.33 inch) |
| through hole Ф154mm(6.06 inch) | ||
| Others | Weight (platform type) | 9300 Kg(20506 lb) |
| Dimensions (L×W×H) | 5100×2200×2650mm | |
| (200×86.6×104.3 inch) | ||
Drilling Equipment
HARMAC
1050M Hydraulic Water Well Drilling Rig HFDX-4+
Model: HFDX-4+
Hydraulic Water Well Drilling Rig is a drilling machine powered by a hydraulic system, designed for efficient water well drilling in various soil and rock conditions. It is widely used for groundwater extraction, agricultural irrigation, and rural water supply projects.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
