| Dimension (LxWxH) | 3870×1300×1470 mm | 152×51×58 in |
| Max.Thrust&Pullback Force | 51 KN | 11460 lbf |
| Max.Thrust&Pullback Speed | 61 m/min | 200 fpm |
| Max.Torque | 2235 N·m | 1684 ft·lb |
| Max.Rotation Speed | 215 r/min | 215 rpm |
| Engine Power | 43 kW | 58 hp |
| Max.Flow of Mud Pump | 75 L/min | 20gal/min |
| Walking Speed | 2.5 km/h | 1.6 mph |
| Max.Mud Pump Pressure | 6 MPa | 870 psi |
| Entry Angle | 14°-17° | 14°-17° |
| Max.Climbing Gradient | 17° | 17° |
| Drill Rod Size | Φ42×1800 mm | Φ1.65×71 in |
| Drill Pipe Box Capacity | 44pcs(4×11) | 44pcs(4×11) |
| Suggest Reaming Diameter | ≤400 mm | ≤16 in |
| Suggest Crossing Length | ≤100 m | ≤328 ft |
Drilling Equipment
Goodeng
Horizontal Directional Drilling Machine GS50-LS
Model: GS50-LS
Horizontal Directional Drill (HDD) is a trenchless drilling machine used to install underground pipes and cables with minimal surface disruption, widely applied in utility and infrastructure construction.
Brand
Goodeng
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
