| JW350 crawler water well drilling rig | |||
| The weight(T) | 7.6 | Drill pipe diameter(mm) | Φ89 Φ102 |
| The hole diameter(mm) | 140-325 | Drill pipe length(m) | 1.5m 2.0m 3.0m 6.0m |
| Drilling depth(m) | 350 | Rig lifting force(T) | 22 |
| One-time advance length(m) | 6.6 | Rapid rise speed(m/min) | 18 |
| Walking speed(km/h) | 2.5 | Fast feeding speed(m/min) | 33 |
| Climbing angles(Max.) | 30 | Width of loading(m) | 2.7 |
| Equipped capacitor(kw) | 93 | Hoisting force of winch(T) | 2 |
| Using air pressure(MPA) | 1.7-3.4 | Swing torque(N.m) | 6200-8500 |
| Air consumption(m³/min) | 17-36 | Dimension(mm) | 5500×1900×2500 |
| Swing speed(rpm) | 66-135 | Equipped with hammer | Medium and high wind pressure series |
| The penetration efficiency(m/h) | 15-35 | High leg stroke(m) | 1.4 |
| The engine brand | DECE/YUCHAI | ||
Drilling Equipment
HARMAC
350M Hydraulic Water Well Drilling Rig JW350
Model: JW350
Hydraulic Water Well Drilling Rig is a drilling machine powered by a hydraulic system, designed for efficient water well drilling in various soil and rock conditions. It is widely used for groundwater extraction, agricultural irrigation, and rural water supply projects.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
