| Specification | 1.2t | 3t | 5t | 8 t | 12t | 14t | |
| Maximum working radius | 5m × 0.3t | 7.8m × 0.2t | 15m×0.2t | 16m × 0.2t | 22×0.6t | 23×1.5t | |
| Maximum ground lift | 5.8mX0.8t | 9.2mX0.8t | 16mX0.8t | 17mX0.9t | 23.5mX0.9t | 14.5mX2t | |
| winch | Hook up speed | 0-8m/min | 0-8m/min | 0-10m/min | _0- 10 m/min | 0-10m/min | 0-10m/min |
| Wire Rope Specifications | Φ8mm × 35m | Φ8mm×45m | Φ 10mm × 80m | Φ10mm × 120m _ | Φ12mm×80m | Φ12mm×80m | |
| Telescopic device | Boom form(U-shaped high-strength manganese) | 4 -section boom , | 5 -section boom , | 5-section lifting arm | 5 -stage boom | 6 stage boom | 5-section boom |
| Boom length/time | 1.7 m- 5 m/2 2 sec | 2.8 m- 8.2 m/2 2 sec | 4m-15m | 4.5m-16m | 5m-22m | 5.5m-23m | |
| undulating device | Boom angle/time | 0-7 5 °/13sec | 0-7 5 °/13sec | 0-75°/13sec | 0-7 5 °/13sec | 0-75°/13sec | 0-75°/13sec |
| gyratory device | Rotation angle/speed | 0-360° (continuous)/60sec | |||||
| landing leg | Outrigger Action Form | Manual unscrewing + hydraulic automatic support (two legs) Oil pressure automatic | |||||
| Maximum extension (mm) Side*Front*Rear | 3120×2950 | 4470×3940 | 5600*5560*5000 | 6400*6500*5400 | 7400*7000*6000 | 7400*7000*6000 | |
| walking device | way of walking | Hydraulic motor drive, two-speed | |||||
| Walking speed | 0-2.5km/h | 0-2.5km/h | 0-5.5km/h | 0-5.5 km /h | 0-5.5km/h | 0-5.5km/h | |
| Gradeability | 20° (36%) | 20° (36%) | 20°(36%) | 20° (36%) | 20°(36%) | 20°(36%) | |
| engine | Type | Electric / Diesel /gasoline | |||||
| Brand | Chinese Brand/ Japan Brand / American Brand / EPA / Euro V | ||||||
| Start method | Electric start | Electric start | Electric start | Electric start | Electric start | Electric start | |
| Startup performance | -5°C~40°C | -5°C~40°C | -5°C~40°C | -5°C~40°C | -5°C~40°C | -5°C~40°C | |
| fuel/volume | Gasoline / 8 L | Diesel / 8 L | Diesel / 45L | Diesel / 45 L | Diesel /55L | Diesel/60L | |
| battery capacity | 12v 45AH | 12v 45AH | 24v 45AH | 24v 45AH | 24v 45AH | 24 v 45 AH | |
| Fuel consumption | 274g/kW-h | 274g/kW-h | 230g/kW-h | 230 g/kW-h | 230g/kW-h | 230g/kW-h | |
| operating system | Type of operation (jib/outrigger), | Manual travel Manual operation, manual walking + remote control (optional) | |||||
| The standard configuration | Diesel engine and electric motor | ||||||
| Vehicle size L*W*H mm | 2260*600*1470mm | 3450*950*1700mm | 4950*1560* 2235mm | 5010*1600*2200mm | 6500*2000*1700mm | 6050*2000*2300mn | |
| Machine weight | 1200kg | 2400kg | 6300kg | 7150kg | 11.5 ton | 15ton | |
Crawler Crane
HARMAC
12 Ton Crawler Crane
Model: XM120
A Crawler crane is a heavy-duty lifting machine mounted on crawler tracks, designed for handling large loads in demanding construction and industrial environments. Its tracked undercarriage provides excellent stability and weight distribution, allowing operation on soft, uneven, or rugged ground without the need for additional support.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
