Characteristic	1.1	Model		EPS15-45	EPS20-45	CDD10II-30	CDD15II-30	CDD20II-30	CDD25II-30	CDD30II-30
	1.2	Power Type		Electric	Electric	Electric	Electric	Electric	Electric	Electric
	1.3	Operation Type		Standing Type	Standing Type	Standing Type	Standing Type	Standing Type	Standing Type	Standing Type
	1.4	Load Capacity	Q(Kg)	1500	2000	1000	1500	2000	2500	3000
	1.5	Load Center	C(mm)	500	500	500	500	500	500	500
	1.6	Bearing Distance	X(mm)	676	676	676	676	676	790	790
	1.7	Wheelbase	Y(mm)	1430	1430	1430	1430	1430	1577	1577
Weight	2.1	Total Weight(With Battery)	kg	1115	1150	1075	1115	1150	1632	1632
Wheels,	3.1	Wheel Type		PU	PU	PU	PU	PU	PU	PU
Chassis	3.2	Front Wheel	∅×w(mm)	Φ80×70	Φ80×70	Φ80×70	Φ80×70	Φ80×70	Φ85×90	Φ85×90
	3.3	Rear Wheel	∅×w(mm)	Φ230×75	Φ230×75	Φ230×75	Φ230×75	Φ230×75	Φ230×75	Φ254×104
	3.4	Front Wheelbase	b2(mm)	490	490	490	490	490	530	530
	3.5	Rear Wheelbase	b3(mm)	658	658	658	658	658	758	758
Dimensions	4.1	Mast Lowered Height	h(mm)	2060	2060	2060	2060	2060	2188	2188
	4.2	Lift Height	h1(mm)	4500	4500	3000	3000	3000	3000	3000
	4.3	Height,mast extended	h2(mm)	5040	5040	3541	3541	3541	3571	3571
	4.4	Handle Height	h5(mm)	1585	1430	1430	1430	1430	1430	1430
	4.5	Fork Clearance When Mast Lowered	h3(mm)	85	85	85	85	85	95	95
	4.6	Overall Length	L(mm)	2185/2605	2185/2605	2185/2605	2185/2605	2185/2605	2235/2655	2235/2655
	4.7	Overall Width	b1(mm)	850	850	850	850	850	1000	1020
	4.8	Fork Size	s/e/l(mm)	65/190/1150	65/190/1150	65/190/1150	65/190/1150	65/190/1150	75/230/1150	75/230/1150
	4.9	Fork Spread	b5(mm)	680	680	680	680	680	760	760
	4.1	Min. Ground Clearance	m2(mm)	30	30	30	30	30	30	30
	4.11	Aisle Width, pallet 1000×1200 (1200 placed across forks) Pedal Folding	Ast(mm)	2615	2615	2615	2615	2615	2715	2715
	4.12	Aisle Width, pallet 1000×1200 (1200 placed across forks) Pedal Open	Ast(mm)	3016	3016	3016	3016	3016	3120	3120
	4.13	Min. Turning Radius	Wa(mm)	1729/2130	1729/2130	1729/2130	1729/2130	1729/2130	1880	1880
Performance	5.1	Travel Speed (Unladen/Laden)	km/h	5.5/5	5.5/5	5.5/5	5.5/5	5.5/5	5月4日	5.5/4
	5.2	Lifting Speed (Unladen/Laden)	m/s	0.1/0.09	0.1/0.086	0.1/0.1	0.1/0.09	0.1/0.086	0.117/0.08	0.117/0.08
	5.3	Lower Speed (Unladen/Laden)	m/s	0.082/0.115	0.082/0.123	0.082/0.112	0.082/0.115	0.082/0.123	0.082/0.140	0.082/0.140
	5.4	Max. gradeability (Unladen/Laden)	%	8月6日	8月4日	8月6日	8月6日	8月4日	6月4日	6月4日
	5.5	Service Brake		Electromagnetic	Electromagnetic	Electromagnetic	Electromagnetic	Electromagnetic	Electromagnetic	Electromagnetic
Motor,	6.1	Drive Motor	kw	1.5	1.5	1.5	1.5	1.5	2.5	3
Charger	6.2	Lift Motor	kw	2.2	2.2	2.2	2.2	2.2	3	3
	6.3	Battery Type		Lead Acid	Lithium	Lead Acid	Lead Acid	Lead Acid	Lead Acid	Lead Acid
	6.4	Battery voltage/nominal capacity	V/Ah	24/210	24V200AH	24/210	24/210	24/210	24/210	24/210
	6.5	Charger	V/A	24/30	24V100A	24/30	24/30	24/30	24/30	24/30
Other	7.1	Type of drive control		AC	AC	AC	AC	AC	AC	AC
Other	7.2	Sound level at the driver’s ear acc. to EN12053	dB(A)	75	75	75	75	75	75	75

Electric Stacker HARMAC

2 Ton Electric Stacker

Model: EPS20

An Electric stacker is a compact, battery-powered material handling equipment designed for lifting, stacking, and transporting palletized goods over short distances. It combines ease of operation with high efficiency, making it an ideal solution for warehouses, retail storage, logistics centers, and light industrial environments.

Brand

HARMAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
