Model			CPD40	CPD45	CPD50
driving mode			seated	seated	seated
rated capacity	Q	kg	4000	4500	5000
load center distance	C	mm	500	500	500
power mode			lead-acid battery	lead-acid battery	lead-acid battery
wheelbase	L1	mm	2040	2040	2040
Tyre
tyre type			Solid	Solid	Solid
front track	W3	mm	1310	1310	1310
rear track	W2	mm	1110	1110	1110
tyre(front)			250-15	250-15	250-15
tyre(rear)			21X8-9	21X8-9	21X8-9
Size
front overhang	L2	mm	573	573	573
height,mast retraction	H1	mm	2340	2340	2340
free lift height	H3	mm	120	120	120
overall maximum lift height	H	mm	3000	3000	3000
height,mast extended	H2	mm	4220(with fork)3790(no fork)	4220(with fork)3790(no fork)	4220(with fork)3790(no fork)
overhead guard height	H4	mm	2350	2350	2350
lateral Fork Adjustment(Outside of Forks)Max/Min	W5	mm	1240/300	1240/300	1240/300
fork size(LxWxT)	TWL4	mm	501451070	501501070	551501070
truck body length(fork excluded)	L’	mm	2990	2990	2990
truck body width	W1	mm	1585	1585	1585
turning radius	R	mm	2700	2700	2700
groubd clearance under mast	H5	mm	160	160	160
Ground clearance at center of wheelbase(laden)	H6	mm	160	160	160
width of aisle right-angle stacking(pallet1000x1000mm clearance 200mm)	Ast	mm	4543	4543	4543
width of aisle right-angle stacking(pallet1200x1200mm clearance 200mm)	Ast	mm	4673	4673	4673

Electric Forklift HARMAC

4 Ton Electric Forklift

Model: CPD40

An Electric forklift is a battery-powered material handling vehicle designed for efficient, low-emission lifting and transportation operations. Compared with internal combustion forklifts, it operates with zero exhaust emissions, low noise levels, and reduced maintenance requirements, making it ideal for indoor environments.

Brand

HARMAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
