Model	MRT-SS12	MRT-SS15	MRT-SS18
Max. Working height	12.0m	15.1m	18.2m
Max. Platform height	10.0m	13.1m	16.2m
Overall length	4.88m	4.88m	4.88m
Overall width	2.30m	2.30m	2.30m
Overal height (unfolded fence)	2.75m	2.95m	3.15m
Overall height (folded fence)	2.1m	2.3m	2.5m
Work plaform dimensions	3.98*1.83	3.98*1.83	3.98*1.83
(length x width)
Platform extension size	1.5m front / 1.2m back	1.5m front / 1.2m back	1.5m front / 1.2m back

Ground clearance	360mm	360mm	360mm
Performance
Maximum number of employees	7	7	4
RATED LOAD	1150kg	680kg	680kg
Extended platform rated load	230kg	230kg	230kg
Machine travel speed (retracted state)	6.1km/h	6.1km/h	6.1km/h
Machine travel speed (lifting state)	1.1km/h	1.1km/h	1.1km/h
Rise/tall time	50/35s	55/45s	60/50s
Gradeability	50%	50%	40%
Minimum turning radius (inner wheel)	2.16m	2.16m	2.16m
Minimum tumning radius (outer wheel)	5.33m	5.33m	5.33m
Maximum allowable angle for work	3°	3°	3°
(front and back)
Maximum allowable angle for work	2°	2°	2°
(lateral,leg retraction)
Maximum alowable angle for work	0.8°	0.8°	0.8°
(front and back, leg extension)
Maximum leg leveling angle	7°	7°	7°
(front and rear)
Maximum allowable angle for work (lateral)	12°	12°	12°
Drive	4WD,2WS	4WD,2WS	4WD,2WS
Tire	33×12-20/Solid foam-filled	33×12-20/Solid foam-filled	33×12-20/Solid foam-filled
Power
Power source	Deutz D2.9L,Stage 5,36KW	Deutz D2.9L,Stage 5,36KW	Deutz D2.9L,Stage 5,36KW
Control voltage	12V DC	12V DC	12V DC
Fuel tank capacity	110L	110L	110L
Hydraulic system capacity	110L	110L	110L
Weight
Whole machine weight	6950kg	7230kg	8020kg

Lifting Equipment HARMAC

15 Meters Scissor Lift

Model: MRT-SS15

A Scissor lift is a vertical lifting platform designed to safely elevate workers, tools, and materials to various working heights. Its crisscross (“scissor”) support structure provides stable vertical movement, making it ideal for maintenance, installation, construction, and warehouse operations.

Brand

HARMAC

Warranty

3 Years

ISO CE Certified
