| MODEL | HA21JE |
| Max.Working Height | 22.55m |
| Max. Platform Height | 20.55m |
| Max. Horizontal Extension | 12.5m |
| Max.Up and Over Height | 8.9m |
| A- Length (Stowed) | 9.05m |
| B- Width (Stowed) | 2.49m |
| C- Height (Stowed) | 2.7m |
| D- Platform Length | 2.4m |
| E- Platform Width | 0.9m |
| F- Wheelbase | 2.5m |
| G- Ground Clearance | 0.31m |
| PERFORMANCE | |
| Platform Capacity | 250kg |
| Max.Drive Speed (Stowed) | 4.8km/h |
| Gradeability | 45% |
| Turning Radius(In.) | 2.42m |
| Turning Radius(Out.) | 5.57m |
| Turntable Rotation | 360°Continuous |
| Platform Rotation | ±80° |
| H Tail Swing | 0.6 |
| Tilt Rating | 5° |
| Operating Wind Speed | 12.5m/s |
| Lift Motor | 11kw |
| Drive Motor | 3.3kw |
| POWER | |
| Batteries(V/Ah) | 48V/440Ah |
| Charger | 100-240VAC/16A |
| Tires | 36X14-20 |
| WEIGHT | |
| Weight | 11000kg |
Aerial Work Platform
HARMAC
21 Meters Aerial Work Platform
Model: HA21JE
An Aerial Work Platform (AWP) is a lifting device designed to safely elevate workers and equipment to perform tasks at height. It provides flexible vertical and horizontal access, making it suitable for maintenance, construction, installation, cleaning, and warehouse operations
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
