Model:FTGKS35	Chassis:FOTON Navigator M5
Total Length(MM):5998	Engine:Full diesel engine Q241106034Z (160HP)
Overall width(MM):2220	Tyre:700mm All-Steel Radial Tire
Overall height (MM):3200	Braking System:Air Brake System
Act. Wt.(KG):6700	Boom Type:7-Segment Drum-Shaped 18-Faceted Arm & 7-Stage Synchronized Telescoping
Max. work height(M):35	Rotator:21 inch disc worm gear integrated turntable(First tier brands) & 360 degree arbitrary rotation
Working radius at maximum height(M):3.7	Platform Max. Load Capacity(KG):200KG
Max. work radius(M):18	Outrigger:X-outrigger,Four double jointed outrigger,individually adjustable
Working height at maximum radius(M):23	Control operation:Work platform and ground remote control operation
Front overhang(MM):1600	Operating system:Electro-hydraulic proportional control system & Realize infinite speed regulation
Rear overhang(MM):1590	Leveling system:Hydraulic Auto-Leveling System
Wheelbase(MM):3360	Upper/Lower Interlock System:Safety Interlock System for Boarding and Alighting to Prevent Accidents.
Transverse Span(MM):6200	Level Detection Function:Real-Time Vehicle Levelness Monitoring.
Longitudinal Span(MM):5700	E-Stop:Real-Time Vehicle Levelness Monitoring.

Aerial Work Platform HARMAC

23 Meters Aerial Work Platform

Model: FTGKS23

An Aerial Work Platform (AWP) is a lifting device designed to safely elevate workers and equipment to perform tasks at height. It provides flexible vertical and horizontal access, making it suitable for maintenance, construction, installation, cleaning, and warehouse operations 品牌 HARMAC

Brand

HARMAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
