| Model | TRTB16E | TRTB20E | TRTB22E | TRTB26E |
| Maximum Working Height | 18.2m | 21.8m | 24m | 27.9m |
| Maximum Platform Height | 16.2m | 19.8m | 22m | 25.9m |
| Maximum Horizontal Reach | 11.9m | 16.6m | 17m | 21.4m |
| Overall Length (Stowed) | 8.5m | 9.76m | 10.9m | 12.8m |
| Overall Width (Stowed) | 2.31m | 2.49m | 2.49m | 2.49m |
| Overall Height (Stowed) | 2.51m | 2.77m | 2.77m | 2.85m |
| Platform Length | 1.83m | 2.44m | 2.44m | 2.44m |
| Platform Width | 0.76m | 0.91m | 0.91m | 0.91m |
| Wheelbase | 2.4m | 2.5m | 2.5m | 2.85m |
| Ground Clearance | 0.3m | 2.1m | 0.305m | 0.32m |
| Track Width | 2.05m | 0.31m | 2.5m | 2.11m |
| Platform Capacity | 300kg | 300kg/450kg | 300kg/450kg | 300kg/450kg |
| Maximum Travel Speed | 4.8km/h | 4.8km/h | 4.8km/h | 4.8km/h |
| Gradeability | 0.4 | 0.45 | 0.45 | 0.45 |
| Inside Turning Radius | 2.62m | 2.42m | 2.9m | 3.28m |
| Outside Turning Radius | 5m | 5.57m | 5.5m | 6.5m |
| Turntable Rotation | 360° | 360° | 360° | 360° |
| Platform Rotation | ±90° | -80°to 80° | 160° | 160° |
| Vertical Jib Rotation | -70°to 70° | -65°to 78° | -65°to 78° | -65°to 78° |
| Maximum Tilt Rating | 5° | 5° | 5° | 5° |
| Working Wind Speed | 12.5m/s | 12.5m/s | 12.5m/s | 12.5m/s |
| Tail Swing Radius | 1.16m | 1.42m | 1.42m | 1.58m |
| Hydraulic Tank Capacity | 70L | 130L | 170L | 140L |
| Overall Weight | 7900kg | 12100kg | 13000kg | 18450kg |
Boom Lift
HARMAC
18 Meters Boom Lift
Model: TRTB16E
A Boom lift is an aerial work platform designed to provide extended vertical and horizontal reach for working at height. Equipped with a hydraulic arm (boom), it allows operators to access hard-to-reach areas that cannot be reached by standard vertical lifts.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
