| Brand | CHENLU |
| Application | Coal/Mine/Stand/Stone Loading |
| Dump Style | Rear Dump |
| Loading Capacity | 30T-100T |
| Axle | 3/4*13/16T |
| CHENLU/FUWA/BPW | |
| Length | 11000mm |
| Width | 2500mm |
| Height | 3600mm |
| Cylinder | HYVA (model is according to the length of cargo box) |
| Floor Plate Thickness | 5mm |
| Cargo Thickness | 4mm |
| Cargo Style | Rectanglular/U-shaped |
| Front Axle Lifting | Available |
| Main Beam | Material Q345/T700 |
| Height: 500mm | |
| Upper Plate: 14mm | |
| Middle Plate: 10mm | |
| Lower Plate: 16mm | |
| Tire | 11.00R20/12R222.5*8/12/16 pieces |
| Linglong/Triangle/Double-Coin | |
| Rim | 8.0/9.0*8/12/16 pieces, steel/aluminum |
| Suspension | Mechanical/Airbag |
| Leaf Spring | 90mm*13/16mm*10 pieces |
| Landing Gear | 28T two-speed, JOST |
| King Pin | #50(2″)/#90(3.5″), JOST/Other Brand |
| Tool Box | Steel/aluminum |
Trailer
HARMAC
3 Axle U-Shaped Dump Trailer
Model: 45CBM
A trailer is a non-powered vehicle designed to be towed by a truck or tractor. It is used to carry goods, equipment, or materials and comes in various types depending on the cargo. Trailers are essential in transportation for moving large or heavy loads efficiently.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
