Item	Specifications	Item	Specifications	Item	Specifications
Overall dimension		Operating weight	10700kg	Speed at forward gear 1	0-38km/h
L×W×H	7100×2520×3170mm	Max.tractive force	≥105kN	Speed at reverse gear 2	0-17km/h
Wheelbase	2850mm	Max.breakout force	≥96kN	Hydraulic system
Min.ground clearance	370mm	Tipping load	≥66kN	Type	Hydraulic pilot control
Max.dumping height	2950-3278mm	Engine		Total time	≤9s
Lifting height	3789mm	Model	YC6J125Z-T20	Brake system
Dumping distance	1020-1050mm	Type	Inline,Water-cooled,wet cylinder,direct injection	Service brake type	Air over hydraulic disc type
Max.gradeability	30	Rated power Speed	92kw/2200r/min	Packing brake type	Electric air control disc brake
Dumping angle	45	Engine displacement	6494mm	Steering system
Bucket rollback at ground level	45	Cylinder bore/stroke	105/125mm	Type	Load-sensing fully hydraulic articulated steering
Width of complete machine(outside of rear wheelM)	2310mm	Max.torque	500Nm	System pressure	12MPa
Wheel tread	1865mm	Emission standard	GB20891 II	Fill capacity
Steering angle	38	Min.fuel-consume ratio	≤235g/kw.h	Fuel	140L
Horizontal crossing radius	5912mm	Transmission system		Hydraulic oil	128L
Min.turing radius	5381mm	Torque converter	Single-stage four-element double-turbine hydraulic torque converter	Engine	17L
Overall parameters		Transmission type	planetary power shift	Transmission	45L
Bucket capacity	1.6-1.8m3	Gears	Forward 2 reverse 1	Bridge	2×18L
Rated load	3000kg	Speed at forward gear 1	0-13km/h	Brake system	4L

Earthmoving Equipment SDLG

3000KG Wheel Loader

Model: SDLG936

A Wheel Loader is a powerful and versatile machine used for loading, moving, and handling bulk materials such as sand, soil, and gravel. It offers high efficiency, strong performance, and flexible operation for construction, mining, and agricultural applications.

Brand

SDLG

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC

Share this product
