| terms | Rear Dump semi trailer | Rear Dump semi trailer |
| Loading Capacity | 40-60 tons | 60-80 tons |
| Axle | 3 axles ,BPW/FUWA axle4 | 4 axles ,BPW/FUWA axle |
| Tyre | 12 pieces, 10.00R20 | 16 pieces, 11.00R20 |
| Dimensions(LxWxH) | 9000 -12000mm x 3000 x 1750mm | |
| Tare weight | 10-12tons | |
| Hydraulic Cylinder | HYVA hydraulic cylinder with one set of PTO | |
| Rims | 8.5-20, 9.0-20 | |
| Suspension System | Leaf spring Suspension/Air suspension | |
| Brake System | Dual line pneumatic brake system with WABCO emergency relay valve | |
| Main Beam | Height 500mm Q345 carbon steel | |
| Chassis | upper 18mm, lower 18mm. Mid web 12mm | |
| Kingpin | 2′ or 3.5′ interchangeable,JOST brand | |
| Landing Gear | 28 Tons , Two speed manual operation | |
| Electrical System | 1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) German standard | |
| Lights and Reflectors | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light | |
| Painting | Shot blast to SA 2.5 Standard prior to application of primer, polyurethane top coat. Total DFT not less than 100μm;Any color will be available | |
| Tool Box | One tool box with a set of standard trailer tools | |
| Spare Tyre Carrier | One piece or two pieces | |
