| Max lifting height | 3350mm |
| Maximum pin height | 2680mm |
| Dumping Height of main boom(dumping angle 45°) | 2000mm |
| Dumping reach of main boom | 1240mm |
| Max. Loading capacity of main boom | 800kg |
| Lifting height of small boom | 2680mm |
| Dumping height of small boom (dumping angle 45°) | 2300mm |
| Max. Loading capacity of small boom | 600kg |
| Wheel base | 1360mm |
| Tread | 20mm |
| Min. Ground clearance | 190mm |
| Turning radius | 2600mm |
| Engine model | RATO739 |
| Engine type | Gasoline engine,Air cooled |
| Rated power | 23HP/3600rpm |
| Max. Torque | 71.5 |
| Speed at Max. Torque(rpm) | 2200 |
Earthmoving Equipment
HARMAC
800KG Telescopic Loader
Model: YH80
A Telescopic loader is a multi-purpose material handling machine equipped with an extendable boom that allows operators to lift, load, and transport materials at varying heights and distances. Combining the capabilities of a wheel loader and a telescopic handler, it provides enhanced reach and flexibility for demanding work environments.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
