| Model: | ZM90 |
| Engine: | YUCHAI |
| Rated Power: | 62.5kW |
| Bucket Capacity: | 0.20~0.50m³ |
| Hydraulic Tank: | ≥75L |
| Max. Digging Height: | ≥7000mm |
| Max. Digging Depth: | ≥4250mm |
| Max. Dumping Height: | ≥5300mm |
| Max. Vertical Digging Depth: | ≥3518mm |
| Max. Digging Radius: | ≥7200mm |
| Max. Ground Digging Radius | ≥7020mm |
| Rotating Speed: | 12.3r/min |
| Max. Traveling Speed: | 35 km/h |
| Gradeability: | 35% |
| Max. Breakout Force: | ≥58kN |
| Working Pressure: | 23MPa |
| Wheelbase | ≥2500mm |
| Wheel Track | ≥1800mm |
| Operating Weight: | 8300kgs |
| Dimension: | 6900 x 2300 x 2900 mm |
Earthmoving Equipment
HARMAC
9 Ton Wheeled Excavator
Model: ZM90
An excavator is a versatile construction machine primarily used for digging, lifting, and moving materials like soil, rock, and debris. It consists of a base (tracked or wheeled), a hydraulic arm, and a bucket. Excavators are essential for construction, mining, and demolition work.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
