| ITEM | TB 904C | |
| Model | / | 90HP,4WD,Electric starter |
| Engine | / | YD 4105ZT,4cylinders,Wter cooling |
| Engine Power | KW | 66.2 |
| Number of shift Gears | / | 12 Front +12 Rear,Reversible Synchronized |
| Differential lock | / | Mechanical Rear Axle Differential Lock |
| Clutch | / | Two-Disc Double-Stage,Dry |
| Front Axle Type | / | Swinging,Portal Type(With final Drives) |
| Tyre Model | / | Rear-11.9-30/ Front 9.5-24 |
| Overall Dimension (L*W*H) | mm | 3950x1780x2710 |
| Wheelbase | mm | 2100 |
| Wheel Tread (Adjustable) | mm | Rear-1440, Front-1310 |
| Min.Ground Clearance | mm | 390 |
| Average Turning Radius | mm | 4750 |
| Structural Weight | kg | 3200 |
| Counter Weight | kg | Rear-180,Front-144 |
| Dashboard | / | Combined Instrument Panel |
| Fuel Tank Volume | L | 90 |
| Type of Roll Protection Device | / | Cabin |
| Steering System Type | / | Hydraulic Steering |
| Hydraulic Suspension System Type | / | Separate |
| Number of Hydraulic Output Groups | / | Two groups with Quick Couplings |
| Type of Suspension | / | Three-Point Hitch |
| Splines of PTO Shaft | / | 8 |
| Standard Speed of PTO Shaft | r/min | 540/1000 |
Agricultrual Equipment
HARMAC
90HP Farm Tractor
Model: TB904
A farm tractor is a powerful vehicle designed for agricultural tasks, primarily used to tow or push farming equipment and machinery. Tractors are essential for various farming operations, such as plowing, tilling, planting, harvesting, and transporting materials.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
