Item	Unit	JH52-XR	JH58-XR	JH62-XR	JH70-XR
Max.theoretical output	m3/h	180	180	180	180
Max.concrete outlet pressure	MPa	8.3	8.3	8.3	8.3
Rated working pressure	MPa	32	32	32	32
Hydraulic system	/	Open circuit	Open circuit	Open circuit	Open circuit
Pumping frequency	min-1	29	29	29	29
Concrete cylinder dia x stroke	mm	260X2100	260X2100	260X2100	260X2200
Rotating angle of turret	•	±360	±360	±360	±360
Max.concrete placing (height/radius/depth)	/	52/47/36.8	56/51/36.6	62/58.6/43	70/66/51
Chassis Model	/	FAW/SINOTRUK/FOTON/-ISUZU/SHACMAN
Max.power	HP	300-420	420~550
Emission standards		EURO 6

Concrete Pump Truck FAW

FAW Pump Truck

Model: JH52-XR

A concrete pump truck is a specialized construction vehicle used to transport and pump liquid concrete to construction sites through a hydraulic pumping system. It is widely used for high-rise buildings, bridges, tunnels, and large construction projects where precise and efficient concrete placement is required.

Brand

FAW

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC

Share this product
