| Model | HBTS40 | HBTS50 | HBTS60 | HBTS80 | ||
| Max. Theoretic capacity | m3/h | 40 | 50 | 60 | 80 | |
| Max, Theoretic pressure | Mpa | 10 | 12 | 12.5 | 15.7 | |
| Motor/Diesel engine power | kw | 45/66 | 55/84 | 90/129 | 110/176 | |
| Max. Theoretic distance | Vertical | m | 120 | 150 | 200 | 250 |
| Horizontal | m | 250 | 300 | 500 | 800 | |
| Disribution valve type | — | S valve | ||||
| Hydraulic oil circuit type | — | Oper Circuit | ||||
| Specification of concrete cylinder | mm | Ø160×1000 | Ø180×1200 | Ø200×1800 | Ø200×1800 | |
| Specification of main oil cylinder | mm | Ø100×1000 | Ø125×1200 | Ø140×1800 | Ø140×1800 | |
| Oil tank capacity | L | 300 | 300 | 420 | 420 | |
| Hopper capacity | L | 600 | 600 | 600 | 600 | |
| Max. Aggregate diameter | mm | Slick scree: 30 | Slick scree: 40 | Slick scree: 50 Scree: 40 | ||
| Scree: 20 | Scree: 30 | |||||
| Dimension (LxWxH) | mm | 4500×1750×1600 | 4800×1800×1650 | 5800×2000×1750 | 5800×2000×1800 | |
| Overall weight | kg | 3200 | 3500 | 5500 | 5800 | |
| pulling speed | km/h | ≤8 | ||||
Concrete Equipment
HARMAC
HBTS40 Concrete Pump
Model: HBTS40
Concrete Pump is a construction machine used to transport and place liquid concrete through pipelines to hard-to-reach areas efficiently. It is widely used in building, bridge, and infrastructure construction projects.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
