| Driving license: | A1,A2,B2 | Announcement Model: | CQ5257ZLJED10384 |
| Drive type: | 6X4 | Wheelbase: | 3800+1400mm |
| Motor: | On the firewood SC10E370Q6 | Gearbox: | Fast 12JSD180T |
| Body length: | 8.31 meters | Body width: | 2.55 meters |
| Vehicle Height: | 3.46 meters | Front track: | 2020mm |
| Rear track: | 1858/1858mm | Vehicle weight: | 12.5 tons |
| Rated load: | 12.37 tons | Total mass: | 25 tons |
| Tonnage Class: | Heavy trucks | Approach Angle: | 16 degrees |
| Departure Corner: | 20 degrees | Origin: | Shandong |
| Market Segments: | Road transport, mining engineering | Fuel Type: | diesel fuel |
| Engine parameters | |||
| Engine Model: | On the firewood SC10E370Q6 | Engine Brand: | On the firewood |
| Number of cylinders: | 6 cylinders | Fuel Type: | diesel fuel |
| Displacement: | 10.42L | Emission Standards: | National VI |
| Maximum horsepower: | 370 hp | Maximum output power: | 272kW |
| Maximum torque: | 1800N·m | Maximum Torque Speed: | 1100-1400rpm |
| Rated speed: | 1900rpm | Engine type: | Compression ignition, direct injection, in-line six-cylinder, water-cooled |
| Container parameters | |||
| Cargo length: | 5.2 meters | Cargo box width: | 2.35 meters |
| Cargo box height: | 1.5 meters | Cargo box form: | Dump |
| Cab parameters | |||
| Cab: | Flat top long | ||
| Transmission parameters | |||
| Transmission model: | Fast 12JSD180T | Transmission brand: | Fast Priest |
| Forward gear: | 12 gears | Number of reverses: | 2 pcs |
| fuel tank | |||
| Fuel Tank Material: | Aluminum alloy | Fuel Tank Capacity: | 400L |
| Chassis parameters | |||
| Frame Size: | 980_865/305×8+4mm | Front axle description: | 7.5T |
| Permissible load on the front axle: | 7000kg | Rear axle description: | HY300H |
| Permissible load on rear axle: | 18000 (two-axle group) kg | Number of springs: | 8\12 |
| tyre | |||
| Tire Specifications: | 11.00R20 18PR | Number of tires: | 10 pcs |
Dump Truck
HONGYAN
HONGYAN 6X4 Dump Truck
Model: 370
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
HONGYAN
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
