Size Parameter	Overall dimension(L×W×H) (mm)		8820×2560×3450
	Wheelbase(mm)		4100+1350
	(/Front Tread/Rear Tread (mm)		2044/1870
	(/)FF/AF(mm)		1495/1000
	Frame Section Size (Hf×Wf×Hf)(mm)		322×80×(10+8)
Refitted Part	Cargo inner dimension (mm)		5800×2300×1500
Quality Parameters	GVW(Kg)		35000
	Chassis weight(Kg)		10587
	/ Chassis weight of Front axle/Rear axle(Kg)		/
	Curb Weight(Kg)		16508
	Rated load (kg)		18492
Performance Parameters	Max speed(Km/h)		80
	Maximum Gradeability(%)		28
	Radius of turning (m)		8.7
Main configuration	Cab	Type	K3W(N944)
		Seat	air seat
		Engine guard	√
		Shroud	×
		AC	√
		Heater	√
		Electric glass	√
		MP3	√
		Cabin suspension	2 springs in front and 2 air bags in rear
		Electronic control flip
		Copilot visor	√
		Central lock
		Radiator protection frame	√
	Body accessories	Tool box	×
		Escalator	×
		Front fender of middle axle	×
		Rear Fence	×
	Engine	Model	WP10.350E53
		Emission levels	E-V
		/ Max output power(hp/rpm)	350/1900
		/ Max torque(N·m/rpm)	1600/1200-1600
		Displacement (cc)	9726
	Clutch	Mode	,,
			Single, dry plate, diaphragm spring
		Specification	Φ430
	Transmission	Mode	12JSD180T+QH70
		Type	MT
		Gear position	R2/R1 7/1 9/3 11/5
			8/2 10/4 12/6
		Gear ratio	15.53/1
		PTO	√
	Front axle	Maximum capacity(Kg)	9000
	Rear axle	Ratio	Benz technology:4.2/4.76;
			Pengxiang:4.26/4.76;
		Maximum capacity (Kg)	16000
	driveshaft	Specification	Φ140×5
	Steering	Type
	Oil	Fuel tank material	Aluminum alloy
		Fuel tank capacity (L)	400
	Brake	Type	Dual-circuit air brake
		ABS	√
		ASR	√
		ESC	√
	Tire	Model	12.00R20 18PR,315/80R22.5 18PR,295/80R22.5 18PR
	(/)Suspension	Type	parapolic leaf spring 10/12
		Front axle stabilizer bar
		Rear axle stabilizer bar
	Electrical System	Batteries	12 volt-140Ah×2
		Alternator	28 volt / 80 amp
		Starter	24 volt / 5.5 KW
	other configuration	Standard: Oil-water separator, PVC sleeper wrap, Integral carpet, front wheel cover, thermal curtain , set of vehicle tools, desert air filter, aluminum alloy gas cylinder with automatic drain valve, air dryer with tire air-pumping interface, E-call, front and rear double tow hook, protection for engine, front and rear headlight protection cover;three-stage pedal
		Optional: liquid heater

Dump Truck JAC

JAC 6X4 Dump Truck

Model: 350

Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.

Brand

JAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
