| Overall Dimension | 13000*3000*1750 |
| (Lx W x H)(mm) | |
| Function | Transport heavy machine |
| Main beam | The height of the beam is 500mm,upper plate is 16mm,middle plate is 18mm,down plate is 10mm. |
| Loading Weight | 60Ton |
| Wheel base(mm) | 6880+1310+1310 |
| Axle Brand | 3*13TON FUWA Axle |
| Suspension | 10 pieces spring steel suspension |
| Tire Type and quantity | 1100R20 radial tires,12units |
| Traction Pin | 50mm or 90mm |
| Landing Gear | 28Ton single speed |
| Brake system | Dual Line braking system,none ABS |
| Platform plate | 3mm |
| Side beam | 16# box iron |
| Container lock | 12pieces |
| Spare tire carriers | 2 sets |
| Tools box | 1 set |
| Brake air chamber | Four double and two single chamber |
| Electrical circuit | 24V,7 ways socket,one set 6-core standard cable |
| Light | Tail lamp with turn signal,brake light&reflector,side lamp etc. |
| Painting | According to the requirement of customers. |
Trailer
HARMAC
Low Bed Semi Trailer
Model: 60TON
A trailer is a non-powered vehicle designed to be towed by a truck or tractor. It is used to carry goods, equipment, or materials and comes in various types depending on the cargo. Trailers are essential in transportation for moving large or heavy loads efficiently.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
