| Model | SVH30 | SVH50 | SVH60 | SVH80 |
| Operating weight(KG) | 330 | 540 | 640 | 800 |
| Static line load(n/cm) | 45 | 45 | 45 | 61.5 |
| Size(mm) | 780*1600*1060 | 780*2480*1050 | 720*1240*1765 | 750*2500*1710 |
| Drum width(mm) | 600 | 600 | 650 | 680 |
| Drum diameter(mm) | 426 | 426 | 380 | 355 |
| Power(kw) | 4.1/3.1/3.7 | 4.7/5.7/4.4 | 9.7/6.6/5.88 | 9.7/6/5.88 |
| Speed(km/h) | 0-3.8 | 0-4 | 0-5 | 0-6 |
| Theoretical climbing ability | 30% | 30% | 30% | 30% |
| vibration frequency(hz) | 70 | 70 | 55 | 65/60 |
| Exciting force(kn) | 20 | 30 | 30 | 30 |
| Fuel(L) | 3.6/1.9/2.5 | 5.9/3.5/6.5 | 5.9/5.5 | 6.5/5.5/10 |
| Lubricant (L) | 0.6/0.75/0.75 | 1.1/1.1/2 | 1.1 | // |
| Hydraulic tank(L) | 2015/12/12 | 18 | 18 | 28 |
| Water tank(L) | 22 | 20/20/— | 22 | 30 |
Road Construction Equipment
HARMAC
SVH50 Road Roller
Model: SVH50
Road Roller is a compaction machine used to compress soil, asphalt, or gravel surfaces to increase density and stability.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
