| Item | Unit | XL2103 |
| Mixing width | mm | 2100 |
| Max. milling depth | mm | 0~400 |
| Rotor diameter | mm | 1280 |
| Min. turning radius | mm | 7100 |
| Manufacturer | Weichai | |
| Cooling mode | Water cooled+ air intercooling | |
| Type | WP12.400N | |
| Air cylinder number | 6 | |
| Rated power | kw | 294 |
| Rated speed | rpm | 1900 |
| Max. fuel consumption rate | g/kW.h | 207.6 |
| Electrical system | 24V | |
| Working speed | km/h | 0~3 |
| Travelling speed | km/h | 0~23 |
| Theoretical gradeability (working gear) | % | 20 |
| Ground clearance | mm | 450 |
| Fuel tank | L | 450 |
| Hydraulic oil tank | L | 450 |
| Machine mass | kg | 15600 |
| Front axle mass | kg | 3200 |
| Rear axle mass | kg | 12300 |
| Mechanical (length x width x height) | mm | 8740*2765*3450 |
Road Construction Equipment
HARMAC
XL2103 Soil Stabilizer
Model: XL2103
Soil Stabilizer is a construction machine used to mix soil with cement, lime, or other binding agents to improve ground strength and stability. It is widely used in road construction, foundation preparation, and ground improvement projects.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
