project		Parameters
Boundary Dimensions (l × w × h)		9500 × 2480 × 3820 mm
Wheel base		4425 mm
Wheel rail		2066/1802 mm
Front/rear overhang		1400/2545 mm
Maximum speed		≥ 90 km/h
Minimum turning diameter		≤ 17 m
Braking distance (full load, initial braking speed 30 km/h)		≤ 10 m
Approach/Departure angles		≥ 18/≥ 12 °
Maximum climbability		≥ 25%
Curb weight	Total mass	17,300 kg
	The first axis	6100 kg
	The second axis	11200 kg
Maximum allowable total mass	Total mass	17,450 kg
	The first axis	6250 kg
	The second axis	11200 kg
Drive type		4 × 2
engine	model	D0836LFLAL
	Emission standards	Country V
	Displacement	6871 L
	Maximum net power	213 kW
	Rated power/speed	215/2300 kW/(r/min)
	Maximum torque/speed	1150/1200 ~ 1750 N·m/(r/min)

Fire Truck XCMG

XCMG Brand 32m New Hydraulic Ladder Fire Truck

Model: DG32K3

Reliable Fire Fighting Vehicles for Municipal, Industrial, Airport, and Emergency Rescue Applications. Available in Water Tank, Foam, Rescue, and Custom Configurations.

Brand

XCMG

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
