| Type | LDHM41 |
| Engine | |
| Model | Cummins 4BTA 3.9 |
| Type | Diesel Engine, liquid cooled, four cylinder |
| Power | 97kw/2200rpm |
| Engine oil volume | 9L |
| Traveling system | |
| Traveling mode | By crawler |
| Driving mode | By hydraulic |
| Steering mode | Collaborative/y\Yaw/Front wheel/Rear wheel/Automatic |
| Traveling speed | 0-30m/min |
| Working speed | 0-15m/min |
| Mold | |
| Mold traverse adjustment | 1000mm |
| Mold height adjustment | 400mm |
| Max. height of the mold | 1300mm |
| Max. width of the mold | 1300mm |
| Vibrating rod | |
| Hydraulic vibrating rod port | 4 |
| Volume | |
| Fuel tank volume | 120L |
| Hydraulic tank volume | 280L |
| Water tank volume | 120L |
| Machine height adjustment | |
| Hydraulic height adjustment | 980mm |
| Mechanical height adjustment | 300mm |
| Dimension | |
| Transport size | 6975x2500x3420mm |
| Weight | 11700kg |
Asphalt Concrete Paver
HARMAC
1.3 Meters Asphalt Paver
Model: LDHM41
An asphalt paver is used to distribute and level hot asphalt mixture evenly on road surfaces, providing smooth, durable, and high-quality pavement during road construction and maintenance..
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
