Parameter	Unit	CDD-A15	CDD-B15	CDD-B20
Rated Capacity (Q)	kg	1500	1500	2000
Load Center Distance (C)	mm	500	500	500
Wheelbase (Y)	mm	1555	960	960
Weight (with battery)	kg	520	580-780	650-860
Wheel Material	–	PU	PU	PU
Front Wheel Size	mm	φ210*75	φ210*75	φ250*75
Rear Wheel Size	mm	φ80*70	φ80*70	φ80*70
Extra Wheel Size	mm	φ100*50	φ100*50	φ100*50
Number of Wheels	–	1X+1/4	1X+2/4	1X+2/4
Front Wheel Track	mm	886	886	886
Rear Wheel Track	mm	525	525	525
Fork Lift Height (H3)	mm	1600/2000/2500/3000/3500	1600/2000/2500/3000/3500	1600/2000/2500/3000/3500
Mast Lowered Height (H1)	mm	2090/1590/1840/2090/2340	2090/1590/1840/2090/2340	2090/1590/1840/2090/2340
Mast Extended Height (H4)	mm	2090/2590/3090/3590/4090	2090/2590/3090/3590/4090	2090/2590/3090/3590/4090
Fork Minimum Ground Clearance (S)	mm	85	85	85
Overall Length (L)	mm	1791	2140	2140
Fork Dimensions	mm	601701100	601701100	601701100
Overall Width (B)	mm	780	800	800
Fork Width (B1)	mm	550	550	550
Aisle Width (1000*1200)	mm	2305	2464	2464
Turning Radius	mm	1431	1600	1600
Travel Speed (Laden/Unladen)	km/h	4月5日	4/5.6	4/5.6
Lift Speed (Laden/Unladen)	m/s	0.12/0.18	0.12/0.18	0.12/0.18
Service Brake	–	Electromagnetic Brake	Electromagnetic Brake	Electromagnetic Brake
Drive Motor Power	kW	0.75	0.75	1.5
Lift Motor Power	kW	2.2	2.2	2.2
Battery (24V)	Ah	85Ah Maintenance-Free	120/210	120/210
Noise Level	dB(A)	<70	<70	<70

Electric Stacker HARMAC

1.5 Ton Electric Stacker

Model: CDD-A15

An Electric stacker is a compact, battery-powered material handling equipment designed for lifting, stacking, and transporting palletized goods over short distances. It combines ease of operation with high efficiency, making it an ideal solution for warehouses, retail storage, logistics centers, and light industrial environments.

Brand

HARMAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
