| specifications | 8t | |
| Maximum homework radius | 16m*0.2t | |
| Maximum ground lift | 17m*0.9t | |
| Winching device | Hook lifting speed | 0-8m/min |
| Specification of steel wire rope | Φ10mm*60m | |
| Telescopic device | Crane arm form | 5-section lifting arm, made of U-shaped manganese steel material |
| Boom length/time | 2.8m-8.2m/20sec | |
| Undulating device | Boom angle/time | 0-75°/13sec |
| gyroscope | Rotation angle/speed | 0-360°/60sec |
| Leg | Leg movement form | Manual rotation+oil pressure automatic support (two legs) |
| Maximum extension amplitude (mm) | 6300mm | |
| running gear | Walking mode | Hydraulic motor drive, two speed |
| Walking speed | 0-2.5km/h | |
| Gradeability | 20° | |
| electrical machinery | voltage | AC380V |
| engine | Type/displacement | 4102 Boosting |
| start mode | Electric start | |
| start performance | -20°C~40°C | |
| fuel | diesel oil | |
| Battery capacity | 12v45Ah | |
| operating system | Operation type (boom/walking) | Manual+remote control (optional) dual operation |
| Standard configuration | Diesel engine and electric motor (dual power) | |
| vehicle size | Length * Width * Height | 4950*1650*2235mm |
| dead-weight | 7.2t | |
Crawler Crane
HARMAC
17 Meters Crawler Crane
Model: XG-SC
A Crawler crane is a heavy-duty lifting machine mounted on crawler tracks, designed for handling large loads in demanding construction and industrial environments. Its tracked undercarriage provides excellent stability and weight distribution, allowing operation on soft, uneven, or rugged ground without the need for additional support.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
