| Model | CP131 |
| Type | long hand bar type |
| Dimension | 2960X1200X1220mm |
| Engine pulley diameter(standard) | 140mm(5.5”) |
| Transmission pulley diameter(standard) | 180mm(7”) |
| Rubber wheel size | 7.50-16 |
| Cage wheel diameter | 800mm |
| Towing pin diameter | 26mm |
| V-belt | Length:1880mm(74”) Qty:2pcs |
| Brake system | small-scale braking |
| Clutch type | dry multiple disc clutch |
| Lubricating oil | SAE90 |
| Lubricating oil capacity | 5.5-6L |
| Tractor Max.Speed | 23.5km/h |
| Transmission Ratio | Low speed 1st Gear:44:1 |
| Mid speed 2nd Gear:23:1 | |
| High speed 3rd Gear:8:1 | |
| Weight(without engine) | 210kgs |
| Diesel Engine Max.Output | 14HP |
Agricultrual Equipment
HARMAC
13HP Walking Tractor
Model: CP13
A walking tractor, also known as a two-wheeled tractor or garden tractor, is a compact, walk-behind agricultural vehicle designed for small-scale farming and gardening tasks. It is typically used for tasks like plowing, tilling, planting, and hauling in smaller or more confined agricultural areas.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
