| Transport Dimension | Overall Operating Weight | 8200KG/10600KG |
| mm L*W*H | 6230×2365×3752 | |
| Wheel base | 2200mm | |
| Min. Ground Clearance | 300mm | |
| Bucket Capacity | 1.0m3 | |
| Breakout Force | 38KN | |
| Loading Lifting Capacity | 2500KG | |
| Bucket Dumping Height | 2650mm | |
| Bucket Dumping Distance | 1025mm | |
| Digging Depth | 52mm | |
| Backhoe Capacity | 0.3 m3 | |
| Max. Digging Depth | 4085mm | |
| Swing Angle of Excavator Grab | 190o | |
| Max. Pulling Force | 39KN | |
| Engine | Model | YC4A105Z-T20 |
| Type | turbocharging four-stroke | |
| Cylinder-Inside Diameter*Stroke | 4-105 | |
| Rated Power | 75KW/100HP | |
| Rated Speed | 2400r/min | |
| Min. Fuel Consumption | 235g/kw.h | |
| Max.Torque | 310NM | |
| Displacement | 4.3L | |
| Transmission System | ||
| Torque Converter | Model | YJ280 |
| Type | Single-stage Three Elements | |
| Max. Efficiency | 84.40% | |
| Inlet Pressure | 0.4Mpa-0.55 Mpa | |
| Outlet Pressure | 1.2Mpa-1.5 Mpa | |
| Cooling Method | Oil-cooling Pressure Circulation | |
| Gearbox | Type | Fixed Shaft Power Transmission |
| Oil Pressure of Clutch | 1373Kpa-1569 Kpa | |
| Gears | Two Gears Ahead, Two Gears Astern | |
| Max.Speed | 22Km/h | |
| Tyre | Model | 14-17.5/19.5L-24 |
| Pressure of Front wheel | 0.22 Mpa | |
| Pressure of Back Wheel | 0.22 Mpa | |
Backhoe Loader
HARMAC
2500KG Backhoe Loader
Model: MC958T
A Backhoe Loader is a versatile construction machine that combines a front loader bucket and a rear backhoe excavator on a single chassis, allowing it to perform both loading and digging operations efficiently. Designed for multi-purpose use, it is widely recognized as one of the most practical and cost-effective machines for small to medium construction projects.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
