| Cab | With air conditioning, direction help, central control | ||||
| Lock, electric glass, multi-function LCD dashboard | |||||
| Driving Type | Manual left hand drive | ||||
| Drive Wheel | 4×2 | ||||
| GVW | 10000(kg) | ||||
| Curb weight | 5000(kg) | ||||
| Loading capacity | 5000(kg) | ||||
| Overall dimensions | 7200*2500*3410(mm) | ||||
| Box dimensions | 4000*2400*550(mm) | ||||
| Allowable passengers in cab | 3 passengers | ||||
| Number of axles | 2 | ||||
| Wheelbase | 3815(mm) | ||||
| Tire specification | 7.00R16 | ||||
| Number of tire | 6+1 | ||||
| Parameters of engine | |||||
| model | Is uzu – 4KH1CN6LB | ||||
| Fuel | Diesel | ||||
| Emission standard | Euro 6 | ||||
| Transmission | ISU ZU 5 speed forward with 1 reverse , Manual | ||||
| Number of cylinder | 4 | ||||
| Cylinder arrangement | Direct-line | ||||
| Electric system | 24(V) | ||||
| Power | 88/120(kw/hp) | ||||
| Displacement | 2.999(L) | ||||
| Maximum torque | 290N.m | ||||
| Air intake form | Supercharged and inter-cooled | ||||
| Cargo box parameter | |||||
| Loading box dimension | 4000*2400*550(mm) | ||||
| Compartment material | Q235,carbon steel | ||||
| The thickness of the side | 1.2mm | ||||
| The thickness of the bottom | 3mm | ||||
| Crane machine configuration | |||||
| Crane model | SQ70-3,CLW brand(3.2 tons 1+2 arms telescope crane) | ||||
| Maximum lift weight(t) | 3.2 | ||||
| Maximum lifting torque(t.m) | 6.72 | ||||
| Crane arm section number | 3 | ||||
| Maximum operating radius(m) | 7.5 | ||||
| Maximum lifting height(m) | 9.5 | ||||
| Rotary speed(r/min) | 2 | ||||
| Rotary range | 360(random) | ||||
| Leg model | H | ||||
| Lifting capacity comparison table | |||||
| Working radius(m) | 2.1 | 3 | 5 | 6 | 7.5 |
| Rated load(kg) | 3200 | 1700 | 900 | 600 | 300 |
| Color | According to your requirements | ||||
Lifting Equipment
Dongfeng
5 Ton Truck Mounted Crane
Model: HTM5E
A Truck Mounted Crane is a lifting machine installed on a truck chassis, combining transportation and lifting capabilities in one efficient unit. It is designed for loading, unloading, and transporting heavy materials while providing flexible lifting operations at different job sites.
Brand
Dongfeng
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
