| Model | 4LZ-7 | 4LZ-8 | ||
| Dimension (L×W×H) | mm | 5450×2520×2870 | 5900×2640×2940 | |
| Min. operating weight(kg) | kg | 3500 | 3935 | |
| rack gauge of crawler | mm | 1150 | 1250 | |
| Feeding speed | kg/s | 5 | 7 | |
| Productivity | hm²/h | 0.27~0.85 | 0.19~1.0 | |
| Working speed | km/h | 0.9~6.5 | 0.9~6.5 | |
| Mini clearance | mm | 300 | 340 | |
| Grain tank | m³ | 1.6 | 1.6 | |
| Fuel tank capacity | L | 140 | 140 | |
| Cutting | Cutting width | mm | 2000 | 2400 |
| Cutting table agitator type | / | Screw pusher type | ||
| Type of reel | / | Eccentric toothed type | ||
| Reel lever lever | / | 5 | ||
| Pulling wheel diameter | mm | Φ900 | ||
| Tuogu Room | Number of threshing drums | / | 1 | |
| Main threshing drum type | / | Φ620×2200 | ||
| Dimensions of the granule drum (outer diameter x length) | mm | Φ620×2000 | Φ620×2200 | |
| Concave plate sieve type | / | Grid format | ||
| Detoxification method | / | Plate-tooth blade type | ||
| Engine | Model | / | 102HP-GIII | 110HP-GIII |
| Type | / | Turbocharging+mechanical injection | ||
| Qty of cylinders | / | 4 | ||
| Rated power | HP/KW | 102HP/75kw | 110HP/80.1kw | |
| Rated speed | r/min | 2600 | 2400 | |
| Fuel consumption per unit operation volume | kg/hm2 | ≤35 | ||
| Unloading system | Unloading height of grain | mm | 800-4000 | |
| Grain unloading mode | / | 270°Multi-directional grain unloading | 360°Multi-directional grain unloading | |
| Rubber Track | / | 450x90x51 | 550x90x56 | |
| Chassis Wheels | / | 6+1 | ||
| Gearbox | / | 90 | 95 | |
| HST | / | KANZAKI 38cc | KANZAKI 52cc | |
| Alarm system | / | Alarma de tanque de granos, alarma de refrigerante, alarma de batería, alarma de aceite del motor, alarma de bloqueo | ||
| Pilothouse | / | Luxury air-conditioned cab | ||
Agricultrual Equipment
HARMAC
Rice Harvester Machine
Model: 4LZ-8
A harvester is a machine used in agriculture to automate the process of harvesting crops. It is designed to efficiently collect mature crops from the fields, reducing the need for manual labor and increasing productivity.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
